| Part Number | COM70T7M17ZLC |
| Mark | ORTUSTECH |
| Gréisst | 7.0 |
| Applikatioun | IA |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 530 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | ORTUSTECH |
| Panel Modell | COM70T7M17ZLC |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 152.4×91.44 mm |
| skizzéieren | 165×105.8×3.65 mm |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | 530 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 40/60 (Max.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S3PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | IA |
| A070VW04 V3 | AUO | 7.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| CLAA070LC05CW | CPT | 7.0 | 800×480 |
| COM70T7M07ZLC | ORTUSTECH | 7.0 | 800×480 |
| COM70T7M17ZLC | ORTUSTECH | 7.0 | 800×480 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| HV070WS1-101 | HYDIS | 7.0 | 1024×600 |
| LD070WU1-SM01 | LG Display | 7.0 | 1200×1920 |
| LTA070B792F | TOSHIBA | 7.0 | 800×480 |
| TX18D37VM0AQA | KOE | 7.0 | 800×480 |
| G190ETN01.0 | AUO | 19.0 | 1280×1024 |
| KG057QV1CA-G020W | Kyocera | 5.7 | 320×240 |
| LJ640U35 | SHARP | 8.9 | 640×400 |
| LM64P30 | SHARP | 9.4 | 640×480 |
| LQ10D367 | SHARP | 10.4 | 640×480 |
| LTD104C11S | TOSHIBA | 10.4 | 640×480 |
| M070SWP1 R4 | IVO | 7.0 | 800×480 |
| NL6448AC33-18A | NLT | 10.4 | 640×480 |
| TCG057QVLHA-G00 | Kyocera | 5.7 | 320×240 |
| TX38D18VM2BAA REV.B | KOE | 15.0 | 1024×768 |
