| Part Number | AM-1024600ITZQW-T00H |
| Mark | AMPIRE |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED , 50K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AMPIRE |
| Écran Gréisst | 10.1 inch |
| Pixel Zuel | 1024(RGB)×600 (WSVGA) 117PPI |
| aktiv Beräich (mm) | 222.72 × 125.28 (H×V) |
| Bezel Beräich (mm) | - |
| luminance | 465 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 262K/16.7M 70% NTSC |
| mass | - |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| Spannungsversuergung | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Modell Numm | AM-1024600ITZQW-T00H |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 255 × 165.8 (H×V×D) |
| Behandlung | Antiglare, Hard coating |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Äntwert | 12/28 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | IPS, Normally Black, Transmissive |
| benotzt fir | Industrial |
| touchscreen | PCAP |
