| Part Number | AM-1024600DTZQW-TA0H |
| Mark | AMPIRE |
| Gréisst | 7.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Panel Mark | AMPIRE |
| Panel Gréisst | 7.0" |
| Resolutioun | 1024(RGB)×600, WSVGA, 170PPI |
| Affichage Beräich | 154.221(W)×85.92(H) mm |
| Kontur Gréisst | 184(W)×128(H) ×12.6(D) mm |
| Hellegkeet | 425 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 58% NTSC |
| Frequenz | 60Hz |
| Gewiicht | - |
| Panel Modell | AM-1024600DTZQW-TA0H |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | - |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | IPS, Normally Black, Transmissive |
| Äntwert Zäit | 13/15 (Typ.)(Tr/Td) |
| Lampe Typ | WLED , 30K hours , With LED Driver |
| Touchscreens | PCAP |
| Applikatioun | Industrial |
