| Part Number | TR-LM7WR3PS |
| Mark | Panasonic |
| Gréisst | 7.0 |
| Applikatioun | DPF |
| Opléisung | 480×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | |
| Faarwen | |
| Géigeliicht | CCFL |
| Interface | Analog |
| Panel Mark | Panasonic |
| Panel Modell | TR-LM7WR3PS |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 480(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 154.08×86.58 mm |
| skizzéieren | 167.5×102.4 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | |
| weisen Faarwen | |
| Äntwert Zäit | |
| Vue Wénkel | 60/60/30/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFL |
| Signal Interface | Analog RGB, 14 pins |
| Input Volt | 12/12V (Typ.)(VI/VBL) |
| Applikatioun | DPF |
| BP070WX1-100 | BOE | 7.0 | 1280×800 |
| CLAA070MA21BW | CPT | 7.0 | 800×600 |
| CLAA070NB02CT | CPT | 7.0 | 1024×600 |
| CLAA070ND23CW | CPT | 7.0 | 1024×600 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LD070WS2-SL04 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| LW700AT9003 | Innolux | 7.0 | 800×480 |
| TR-LM7WR3PS | Panasonic | 7.0 | 480×234 |
| A104SN03 V0 | AUO | 10.4 | 800×600 |
| AT070TN01 | Innolux | 7.0 | 480×234 |
| CLAA101ND02CW | CPT | 10.1 | 1024×600 |
| CLAA104XA01CW | CPT | 10.4 | 1024×768 |
| HSD100IFW3-A00 | HannStar | 10.1 | 1024×600 |
| LQ090Y3DG01 | SHARP | 9.0 | 800×480 |
| LSA40AT9001 | Innolux | 10.4 | 800×600 |
| LTA104S1-L01 | Samsung | 10.4 | 800×600 |
| PM102ZY2 | E Ink | 10.2 | 1024×600 |
| TM070SDH03 | Tianma | 7.0 | 800×600 |
