| Part Number | 70WVW1T |
| Mark | SII |
| Gréisst | 7.0 |
| Applikatioun | CNS |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 360 |
| CR | 400:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SII |
| Panel Modell | 70WVW1T |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 152.4×91.44 mm |
| skizzéieren | 165×105.8×4.8 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 360 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 16.2M (6-bit + Dithering), CIE193145% |
| Äntwert Zäit | 5/11 (Typ.)(Tr/Td) |
| Vue Wénkel | 70/70/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S3PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | CNS |
| 70WVW1A | SII | 7.0 | 800×480 |
| 70WVW1T | SII | 7.0 | 800×480 |
| 70WVW2A | SII | 7.0 | 800×480 |
| 70WVW2T | SII | 7.0 | 800×480 |
| 70WVW3A | SII | 7.0 | 800×480 |
| 70WVW3T | SII | 7.0 | 800×480 |
| 70WVW4A | SII | 7.0 | 800×480 |
| 70WVW5A | SII | 7.0 | 800×480 |
| HV070WS1-101 | HYDIS | 7.0 | 1024×600 |
| LQ070T5BG01 | SHARP | 7.0 | 480×234 |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C070VW04 VB | AUO | 7.0 | 800×480 |
| C102EVN01.0 | AUO | 10.2 | 1280×720 |
| DLC0700CZG-6 | Other | 7.0 | 800×480 |
| L5F30947T00 | Epson | 6.5 | 800×480 |
| LQ042T5DZ01 | SHARP | 4.2 | 480×272 |
| LQ070Y5DG01 | SHARP | 7.0 | 800×480 |
| TM062RDS01 | Tianma | 6.2 | 800×480 |
| YXDK050TN02-40NM03 | SEBO | 5.0 | 800×480 |
