| Part Number | WS020ZVM-N30-6KP0 |
| Mark | BOE |
| Gréisst | 2.0 |
| Applikatioun | Wearable Round Displ |
| Opléisung | 640×572 |
| Zesummesetzung | LTPS TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Mark | BOE |
| Modell | WS020ZVM-N30-6KP0 |
| diagonal Gréisst | 2.0 inch |
| Typ | LTPS TFT-LCD, LCM |
| Pixel Format | 640(RGB)×572 327PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 49.728(H)×44.364(V) mm |
| kontur dim. | 52.1(H)×49.8(V) mm |
| luminance | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 70% NTSC |
| Liichtquell | WLED [4S1P] , W/O Driver |
| Gewiicht | - |
| entworf fir | Wearable Round Display |
| Frame Taux | 60Hz |
| Touch Panel | PCAP |
| Interface Typ | MIPI (1 data lane) , 30 pins Connector |
| Stroumversuergung | 1.8/5.0/-5.0V (Typ.)(IOVCC/VSP/VSN) |
| Ëmwelt | Operating Temperature: -10 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
