| Part Number | WEA012864DLPP3N00003 |
| Mark | Winstar |
| Gréisst | 0.96 |
| Applikatioun | Instruments & Meters |
| Opléisung | 128×64 |
| Zesummesetzung | OLED , PM-OLED |
| Hellegkeet | |
| CR | |
| Faarwen | Mono(Yellow) |
| Géigeliicht | self |
| Interface | 4-wire |
| Fabrikant beschwéiert | Winstar |
| Écran Gréisst | 0.96 inch |
| Pixel Zuel | 128×64 149PPI |
| aktiv Beräich (mm) | 21.74 × 10.86 (H×V) |
| Bezel Beräich (mm) | 23.94 × 12.06 (H×V) |
| Vue Wénkel | - |
| gutt Vue op | Symmetry |
| Faarfdéift | Mono(Yellow) |
| mass | - |
| Erfrëschungsrate | - |
| Chauffer ic Lëscht | Built-in COG SSD1306BZ |
| Signal Typ | 4-wire SPI, I²C , 8 pins PIN |
| Spannungsversuergung | 3.3/5.0/7.5V (Typ.) |
| max. Bewäertungen | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 80 °C |
| Modell Numm | WEA012864DLPP3N00003 |
| Écran Typ | OLED , PM-OLED |
| Arrangement | Rectangle |
| Kontur (mm) | 38 × 28.5 × 4.37 (H×V×D) |
| Behandlung | - |
| Äntwert | - |
| Aarbecht Modus | - |
| benotzt fir | Instruments & Meters |
| touchscreen | Without |
