| Part Number | WEA012864DBPP3N00001 |
| Mark | Winstar |
| Gréisst | 0.96 |
| Applikatioun | Instruments & Me |
| Opléisung | 128×64 |
| Zesummesetzung | PM-OLED, OLED |
| Hellegkeet | |
| CR | |
| Faarwen | Mono(Blue) |
| Géigeliicht | self |
| Interface | |
| Mark | Winstar |
| Modell | WEA012864DBPP3N00001 |
| diagonal Gréisst | 0.96 inch |
| Typ | PM-OLED, OLED |
| Pixel Format | 128×64 149PPI |
| Configuratioun | Rectangle |
| aktiv Beräich | 21.74(H)×10.86(V) mm |
| kontur dim. | 38(H)×28.5(V) ×4.37(D) mm |
| bezel Beräich | 23.94(H)×12.06(V) mm |
| Behandlung | - |
| Vue Richtung | Symmetry |
| Äntwert Zäit | - |
| Vue Wénkel | - |
| Betribssystemer Modus | - |
| Ënnerstëtzung Faarf | Mono(Blue) |
| Liichtquell | self |
| Gewiicht | - |
| entworf fir | Instruments & Meters |
| Frame Taux | - |
| Touch Panel | Without |
| Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
| IROP018-010-0128064-W | Other | 0.96 | 128×64 |
| L3P10Y-81G00 | Epson | 0.96 | 1400×1050 |
| OEL9M0083-G-E | Other | 0.96 | 128×64 |
| OEL9M0083-R-E | Other | 0.96 | 128×64 |
| OEL9M0083-W-E | Other | 0.96 | 128×64 |
| OEL9M0083-Y-E | Other | 0.96 | 128×64 |
| RGS10128064WR010 | RiTdisplay | 0.96 | 128×64 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HSWEG01 | WiseChip | 0.96 | 128×64 |
