| Part Number | VS035ZSM-NW0-69P0 |
| Mark | BOE |
| Gréisst | 3.5 |
| Applikatioun | HMD VR AR |
| Opléisung | 1440×1600 |
| Zesummesetzung | LTPS TFT-LCD , LCM |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | BOE |
| diagonal Gréisst | 3.5 inch |
| Pixel Format | 1440(RGB)×1600 615PPI |
| aktiv Beräich | 59.4(H)×66(V) mm |
| bezel Beräich | - |
| luminance | 200 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 70/70/70/70 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 85% NTSC |
| Gewiicht | 17.0±2.0g |
| Frame Taux | 90Hz |
| Modell | VS035ZSM-NW0-69P0 |
| Typ | LTPS TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 62.2(H)×73.6(V) mm |
| Behandlung | Without Polarizer, Hard coating (3H) |
| Kontrast Verhältnis | 700:1 (Typ.) (TM) |
| Äntwert Zäit | 5 (Max.)(G to G) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Liichtquell | WLED [5S2P] , W/O Driver |
| entworf fir | HMD VR AR |
| Touch Panel | Without |
