Innolux V460H1-LS2 Rev.C7 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


V460H1-LS2 Rev.C7

V460H1-LS2 Rev.C7
V460H1-LS2 Rev.C7
V460H1-LS2 Rev.C7 thumb V460H1-LS2 Rev.C7 thumb
Mark
Innolux
Gréisst
46
Applikatioun
LCTV
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
370
CR
5000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
19
Spezifikatioune

Part Number V460H1-LS2 Rev.C7
MarkInnolux
Gréisst46
ApplikatiounLCTV
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet370
CR5000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkCHIMEI INNOLUX
Panel ModellV460H1-LS2 Rev.C7
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst46 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusSuper MVA, Normally Black, Transmissive
aktiv Beräich1018.08×572.67 mm
skizzéieren1056.9×612.3 mm
UewerflächAntiglare (Haze 11%), Hard coating
Hellegkeet370 cd/m² (Typ.)
Kontrast Verhältnis5000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit6 (Typ.)(G to G)
Vue Wénkel88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
Frequenz120Hz (60Hz Input)
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 10-bit), 61 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
LTY460HQ05-A01 Samsung 46 1920×1080
T460HW03 VB AUO 46 1920×1080
V460H1-L09 Innolux 46 1920×1080
V460H1-L12 Innolux 46 1920×1080
V460H1-LE3 Innolux 46 1920×1080
V460H1-LH9 Innolux 46 1920×1080
V460H1-LS1 Innolux 46 1920×1080
V460H1-LS1 Rev.C6 Innolux 46 1920×1080
V460H1-LS2 Innolux 46 1920×1080
V460H1-LS2 Rev.C7 Innolux 46 1920×1080
