V460H1-LS1 Rev.C6

V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6 thumb V460H1-LS1 Rev.C6 thumb V460H1-LS1 Rev.C6 thumb
Mark
Innolux
Gréisst
46
Applikatioun
LCTV
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
350
CR
6000:1
Faarwen
1.07B
Backlight
WLED
Interface
LVDS
In Stock
19025
Spezifikatioune

Part Number V460H1-LS1 Rev.C6
MarkInnolux
Gréisst46
ApplikatiounLCTV
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet350
CR6000:1
Faarwen1.07B
GéigeliichtWLED
InterfaceLVDS
Panel MarkCHIMEI INNOLUX
Panel ModellV460H1-LS1 Rev.C6
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst46 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusSuper MVA, Normally Black, Transmissive
aktiv Beräich1018.08×572.67 mm
skizzéieren1076.5×634.7 mm
UewerflächAntiglare (Haze 11%), Hard coating (3H)
Hellegkeet350 cd/m² (Typ.)
Kontrast Verhältnis6000:1 (Typ.)
weisen Faarwen1.07B (8-bit + Hi-FRC), CIE193172%
Äntwert Zäit6 (Typ.)(G to G)
Vue Wénkel88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
Frequenz120Hz
Lampe Typ4 stringsWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 10-bit), 102 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
LTA460HQ16 Samsung 46 1920×1080
T460HW04 V8 AUO 46 1920×1080
V460H1-L09 Innolux 46 1920×1080
V460H1-L12 Innolux 46 1920×1080
V460H1-LE3 Innolux 46 1920×1080
V460H1-LH9 Innolux 46 1920×1080
V460H1-LS1 Innolux 46 1920×1080
V460H1-LS1 Rev.C6 Innolux 46 1920×1080
V460H1-LS2 Innolux 46 1920×1080
V460H1-LS2 Rev.C7 Innolux 46 1920×1080
