| Part Number | V315H3-L02 |
| Mark | Innolux |
| Gréisst | 31.5 |
| Applikatioun | LCTV |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 6000:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | CHIMEI INNOLUX |
| Panel Modell | V315H3-L02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 31.5 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | MVA, Normally Black, Transmissive |
| aktiv Beräich | 698.4×392.85 mm |
| skizzéieren | 760×450 mm |
| Uewerfläch | Antiglare (Haze 11%), Hard coating (3H) |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 6000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 8.5ms |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLEmbedded (Balance board) |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| LC320EUN-SFF1 | LG Display | 31.5 | 1920×1080 |
| LC320WUD-SCA1 | LG Display | 31.5 | 1920×1080 |
| LD320EUN-SEM1 | LG Display | 31.5 | 1920×1080 |
| V315B6-L02 | Innolux | 31.5 | 1366×768 |
| V315H3-L01 | Innolux | 31.5 | 1920×1080 |
| V315H3-L02 | Innolux | 31.5 | 1920×1080 |
| V315H3-LE1 | Innolux | 31.5 | 1920×1080 |
| V315H3-LE3 | Innolux | 31.5 | 1920×1080 |
| V315H4-LE2 | Innolux | 31.5 | 1920×1080 |
| V315H4-LE3 | Innolux | 31.5 | 1920×1080 |
| AX080D002F | KOE | 31.5 | 1366×768 |
| HK185LEDM-CH25H | Other | 18.5 | 1366×768 |
| LC230WX3-SLA1 | LG Display | 23.0 | 1366×768 |
| LC320DXE-SFR1 | LG Display | 31.5 | 1366×768 |
| LC370W01-A6 | LG Display | 37 | 1366×768 |
| LC420EUH-PEF1 | LG Display | 42 | 1920×1080 |
| LC420EUN-SFF2 | LG Display | 42 | 1920×1080 |
| LC550EUN-PEF1 | LG Display | 55 | 1920×1080 |
| LTA520HB03 | Samsung | 52 | 1920×1080 |
| V315B5-LE2 | Innolux | 31.5 | 1366×768 |
