| Part Number | UMSH-8377MD-8T |
| Mark | Other |
| Gréisst | 5.7 |
| Applikatioun | IA |
| Opléisung | 640×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 600:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | URT |
| Panel Modell | UMSH-8377MD-8T |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.7 inch |
| Resolutioun | 640(RGB)×480 , VGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 115.2×86.4 mm |
| skizzéieren | 127×98.43×10.06 mm |
| Uewerfläch | |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 15/35 (Typ.)(Tr/Td) |
| Vue Wénkel | 75/75/60/75 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | IA |
