| Part Number | UG-2864KSWMG01 |
| Mark | WiseChip |
| Gréisst | 1.54 |
| Applikatioun | IA |
| Opléisung | 128×64 |
| Zesummesetzung | OLED |
| Hellegkeet | 120 |
| CR | 10000:1 |
| Faarwen | Mono(White) |
| Géigeliicht | self |
| Interface | CPU/SPI/I²C |
| Panel Mark | WiseChip |
| Panel Modell | UG-2864KSWMG01 |
| Panel Typ | PM-OLED , OLED |
| Panel Gréisst | 1.54 inch |
| Resolutioun | 128×64 |
| aktiv Beräich | 35.052×17.516 mm |
| skizzéieren | 42.04×27.22×1.55 mm |
| Uewerfläch | |
| Hellegkeet | 120 cd/m² (Typ.) |
| Kontrast Verhältnis | 10000 : 1 (Typ.) |
| weisen Faarwen | Mono(White) |
| Vue Wénkel | |
| Chauffeur ic | Built-in SSD1309 |
| Signal Interface | 8-bit 6800/8080 parallel, 4-wire SPI, I²C |
| rohs: | |
| Applikatioun | IA |
| UG-2864ALBPG01 | WiseChip | 2.4 | 128×64 |
| UG-2864ASGPG01 | WiseChip | 2.4 | 128×64 |
| UG-2864ASWIG01 | WiseChip | 2.7 | 128×64 |
| UG-2864ASYCG01 | WiseChip | 1.54 | 128×64 |
| UG-2864ASYDT01 | WiseChip | 2.7 | 128×64 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864KLBMG01 | WiseChip | 1.54 | 128×64 |
| UG-2864KSWLG01 | WiseChip | 1.3 | 128×64 |
| UG-2864KSWMG01 | WiseChip | 1.54 | 128×64 |
| UG-2864KSYMG01 | WiseChip | 1.54 | 128×64 |
| EL160.120.39 | Lumineq | 3.1 | 160×120 |
| LM215WF3-SLC1 | LG Display | 21.5 | 1920×1080 |
| LQ121S1DG21A | SHARP | 12.1 | 800×600 |
| LQ150X1LG82 | SHARP | 15.0 | 1024×768 |
| MD640.400-54 | FINLUX | 9.1 | 640×400 |
| NL6448BC18-01F | NLT | 5.7 | 640×480 |
| PD080SY1 | E Ink | 8.0 | 800×600 |
| RGS15128128YR000 | RiTdisplay | 1.5 | 128×128 |
| TM150TDSG70 | Tianma | 15.0 | 1024×768 |
| TX26D202VM0BAA | KOE | 10.1 | 1920×1200 |
