| Part Number | TX31D41VM2BAA |
| Mark | KOE |
| Gréisst | 12.1 |
| Applikatioun | IA |
| Opléisung | 800×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | |
| Faarwen | |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | HITACHI |
| Panel Modell | TX31D41VM2BAA |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 12.1 inch |
| Resolutioun | 800(RGB)×600 , SVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 246×184.5 mm |
| skizzéieren | 270×207.5 mm |
| Uewerfläch | |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | |
| weisen Faarwen | |
| Äntwert Zäit | |
| Vue Wénkel | |
| Lampe Typ | 2 pcsCCFL |
| Signal Interface | LVDS (1 ch, 6-bit) |
| Applikatioun | IA |
