| Part Number | TX26D207VM0AAA |
| Mark | KOE |
| Gréisst | 10.1 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | KOE |
| diagonal Gréisst | 10.1 inch |
| Pixel Format | 1280(RGB)×800 [WXGA] 149PPI |
| aktiv Beräich | 217.344(H)×135.84(V) mm |
| bezel Beräich | 220.344(H)×138.838(V) mm |
| luminance | 1000 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 65% NTSC |
| Gewiicht | 340g (Typ.) |
| Frame Taux | 60Hz |
| Interface Typ | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| Modell | TX26D207VM0AAA |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 231(H)×153.5(V) ×11.07(D) mm |
| Behandlung | - |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Äntwert Zäit | 25 (Max.)(Tr+Tf) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Liichtquell | WLED , 70K hours , With LED Driver |
| entworf fir | Industrial Outdoor High Brightness Automotive Display |
| Touch Panel | Without |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| HSD100IFW1-F03 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| LP101WH1-TLB1 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB2 | LG Display | 10.1 | 1366×768 |
| LP101WX1-SLP2 | LG Display | 10.1 | 1280×800 |
| LTN101NT02-B01 | Samsung | 10.1 | 1024×600 |
| N101ICG-L21 Rev.B1 | Innolux | 10.1 | 1280×800 |
| TX26D202VM0BAA | KOE | 10.1 | 1920×1200 |
| TX26D203VM2BAA | KOE | 10.4 | 1024×768 |
