| Part Number | TX20D208VM0BAA |
| Mark | HITACHI |
| Gréisst | 8.0 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | HITACHI |
| Panel Modell | TX20D208VM0BAA |
| Panel Gréisst | 8.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 800(RGB)×480, WVGA, 116PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 174(W)×104.4(H) mm |
| bezel Ouverture | 177.4(W)×107.8(H) mm |
| Kontur Gréisst | 190.8(W)×120.5(H) ×16.2(D) mm |
| Uewerfläch | - |
| Hellegkeet | 1200 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | IPS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 30 (Max.)(Tr+Td) |
| weisen Faarwen | 16.7M 70% NTSC |
| Lampe Typ | WLED , 100K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 275g (Typ.) |
| Applikatioun | Industrial Outdoor High Brightness Automotive Display |
| Signal Interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
