| Part Number | TX18D210VM0BAA |
| Mark | KOE |
| Gréisst | 7.0 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 800×480 |
| Zesummesetzung | LCM , LTPS TFT-LCD |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 262K |
| Géigeliicht | WLED , 50K hours , With LED Driver |
| Interface | Parallel |
| Fabrikant beschwéiert | KOE |
| Écran Gréisst | 7.0 inch |
| Pixel Zuel | 800(RGB)×480 (WVGA) 133PPI |
| aktiv Beräich (mm) | 152.4 × 91.44 (H×V) |
| Bezel Beräich (mm) | 156.2 × 94.5 (H×V) |
| luminance | 800 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 262K 72% NTSC |
| mass | 214g (Typ.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| Modell Numm | TX18D210VM0BAA |
| Écran Typ | LCM , LTPS TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 167.7 × 109.5 × 20.3 (H×V×D) |
| Behandlung | - |
| Kontrast Verhältnis | 1200 : 1 (Typ.) (TM) |
| Äntwert | 30 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | IPS, Normally Black, Transmissive |
| benotzt fir | Industrial Outdoor High Brightness Automotive Display |
| touchscreen | Without |
