| Part Number | HSD070PFW3-C01 |
| Mark | HannStar |
| Gréisst | 7.0 |
| Applikatioun | CNS |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 600 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | HannStar |
| Panel Modell | HSD070PFW3-C01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 1024(RGB)×600 , WSVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 153.6×90 mm |
| skizzéieren | 164.4×102.2×6 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193150% |
| Äntwert Zäit | 4/12 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 3S8PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 40 pins |
| Input Volt | 3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VHL) |
| Applikatioun | CNS |
| A070VW08 V2 | AUO | 7.0 | 800×480 |
| AT070TN92 V.1 TP | Innolux | 7.0 | 800×480 |
| HSD070PFW1-A00 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-B02 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-D00 | HannStar | 7.0 | 1024×600 |
| HSD070PWW1-B01 | HannStar | 7.0 | 1280×800 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| PM070WL4 | E Ink | 7.0 | 800×480 |
| Q07021-701 | Innolux | 7.0 | 800×600 |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| AT102TN03 V.3 | Innolux | 10.2 | 800×480 |
| C065VL01 V0 | AUO | 6.5 | 800×480 |
| C070VTN01.0 | AUO | 7.0 | 800×480 |
| DLC1040ABG-T-2 | Other | 10.4 | 800×600 |
| LQ065T5GA01 | SHARP | 6.5 | 400×234 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
| PM100WX2 | E Ink | 10.0 | 800×480 |
| TFD58W22MW | TOSHIBA | 5.8 | 400×234 |
| TX15D02VM0CAA | KOE | 5.8 | 400×240 |
