| Part Number | TV101WXM-NS0 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6 |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Gréisst | 10.1" |
| Resolutioun | 1280(RGB)×800, WXGA, 149PPI |
| Affichage Beräich | 216.96(W)×135.6(H) mm |
| Kontur Gréisst | 228.211(W)×148.86(H) ×4.59(D) mm |
| Hellegkeet | - |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 50% NTSC |
| Frequenz | 60Hz |
| Panel Gewiicht | 130g (Typ.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 45 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 80 °C |
| Panel Modell | TV101WXM-NS0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Hard coating (2H), Antireflection |
| Kontrast Verhältnis | 900:1 (Typ.) (TM) |
| Display Modus | ADS, Normally Black, Transmissive |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Lampe Typ | 6 strings WLED , Without Driver |
| Touchscreens | Without |
| Applikatioun | Pad & Tablet |
