| Part Number | TM080RBHG30 |
| Mark | TIANMA |
| Gréisst | 8.0 |
| Applikatioun | Industrial |
| Opléisung | 800×480 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | 3S12P WLED , 20K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM080RBHG30 |
| Écran Gréisst | 8.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 800(RGB)×480 (WVGA) 116PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 176.64 × 99.36 (H×V) |
| Kontur (mm) | 192.8 × 116.9 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 375 cd/m² (Typ.) |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Vue Wénkel | 70/70/60/70 (Typ.)(CR≥10) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| gutt Vue op | - |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 262K/16.7M 65% NTSC |
| mass | 280g (Typ.) |
| benotzt fir | Industrial |
| Erfrëschungsrate | 60Hz |
| touchscreen | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| LD080UX1-SMA2 | LG Display | 8.0 | 1200×1600 |
| TM080SDH01 | Tianma | 8.0 | 800×600 |
| TM080SV-04L01 | SANYO | 8.0 | 800×600 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| TM080XPH01 | Tianma | 8.0 | 1280×768 |
