| Part Number | TM070RDHG34 |
| Mark | TIANMA |
| Gréisst | 7.0 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 800×480 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 3S8P WLED , 50K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM070RDHG34 |
| Écran Gréisst | 7.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 800(RGB)×480 (WVGA) 134PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 154.08 × 85.92 (H×V) |
| Kontur (mm) | 164.9 × 100 × 6 (H×V×D) |
| Bezel Beräich (mm) | 157.08 × 89.39 (H×V) |
| Behandlung | Antiglare |
| luminance | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Vue Wénkel | 70/70/60/70 (Typ.)(CR≥10) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 16.7M 50% NTSC |
| mass | TBD |
| benotzt fir | Industrial Outdoor High Brightness Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
