| Part Number | TM070RDH10-00 |
| Mark | TIANMA |
| Gréisst | 7.0 |
| Applikatioun | Industrial Digital P |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | TIANMA |
| diagonal Gréisst | 7.0 inch |
| Pixel Format | 800(RGB)×480 [WVGA] 134PPI |
| aktiv Beräich | 154.08(H)×85.92(V) mm |
| bezel Beräich | 157.08(H)×89.39(V) mm |
| luminance | 450 cd/m² (Typ.) |
| Vue Richtung | 12 o'clock |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 262K/16.7M 50% NTSC |
| Gewiicht | TBD |
| Frame Taux | 60Hz |
| Modell | TM070RDH10-00 1 Compatible |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 164.9(H)×100(V) ×6(D) mm |
| Behandlung | Antiglare |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Liichtquell | WLED [3S8P] , 20K hours , W/O Driver |
| entworf fir | Industrial Digital Photo Frame Portable DVD Player |
| Touch Panel | Without |
| LB070WV6-TD06 | LG Display | 7.0 | 800×480 |
| PM070WT2 | E Ink | 7.0 | 800×480 |
| PW070NS1W2 | E Ink | 7.0 | 480×320 |
| Q070LRE-LB1 | Innolux | 7.0 | 1024×600 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TX18D41VM0EAA | KOE | 7.0 | 1024×600 |
