| Part Number | TM050RBH01-00 |
| Mark | TIANMA |
| Gréisst | 5.0 |
| Applikatioun | Industrial Portable |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 450:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Parallel |
| Mark | TIANMA |
| Modell | TM050RBH01-00 |
| diagonal Gréisst | 5.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×480 [WVGA] 188PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 108(H)×64.8(V) mm |
| kontur dim. | 120.7(H)×75.8(V) ×6.3(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 450:1 (Typ.) (TM) |
| Vue Richtung | 12 o'clock |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 50% NTSC |
| Liichtquell | WLED [6S3P] , 20K hours , W/O Driver |
| Gewiicht | 76.3g |
| entworf fir | Industrial Portable Navigation MID UMPC MP3 PMP |
| Frame Taux | 60Hz |
| Touch Panel | 4-wire Resistive Touch |
| Interface Typ | Parallel RGB (1 ch, 8-bit) , 45 pins FPC |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
