| Part Number | TM043NDH02 |
| Mark | Tianma |
| Gréisst | 4.3 |
| Applikatioun | PND |
| Opléisung | 480×272 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | TIANMA |
| Panel Modell | TM043NDH02 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 4.3 inch |
| Resolutioun | 480(RGB)×272 , WQVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 95.04×53.856 mm |
| skizzéieren | 105.5×67.2×3.2 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193150% |
| Äntwert Zäit | 20 (Max.)(Tr+Td) |
| Vue Wénkel | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 5S2PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PND |
| AM-480272-043D | Other | 4.3 | 480×272 |
| AT043TN25 V.2 | Innolux | 4.3 | 480×272 |
| HSD043I9W1-A00 | HannStar | 4.3 | 480×272 |
| LQ043T1DG03B | SHARP | 4.3 | 480×272 |
| LQ043T3DX03 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03A | SHARP | 4.3 | 480×272 |
| LQ043T3DX0F | SHARP | 4.3 | 480×272 |
| LS043K1SX02 | SHARP | 4.3 | 720×1280 |
| TM043NDH02 | Tianma | 4.3 | 480×272 |
| YX-CM043-QN05-56 | 4.3 | 480×272 |
| 35QVW1T | SII | 3.5 | 320×240 |
| 43WQW3H | SII | 4.3 | 480×272 |
| 43WQW3T | SII | 4.3 | 480×272 |
| 990000475P | TPO | 4.3 | 800×480 |
| AT043TN13 | Innolux | 4.3 | 480×272 |
| AT050TN34 V.1 | Innolux | 5.0 | 480×272 |
| LMS480KC01 | Samsung | 4.8 | 800×480 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| LTE480WV-F01 | Samsung | 4.8 | 800×480 |
