| Part Number | TL079QDXP01 |
| Mark | TIANMA |
| Gréisst | 7.9 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1536×2048 |
| Zesummesetzung | LTPS TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Mark | TIANMA |
| Modell | TL079QDXP01 |
| diagonal Gréisst | 7.9 inch |
| Typ | LTPS TFT-LCD, LCM |
| Pixel Format | 1536(RGB)×2048 325PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 119.808(H)×159.744(V) mm |
| kontur dim. | - |
| luminance | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Betribssystemer Modus | SFT, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 70% NTSC |
| Liichtquell | WLED |
| Gewiicht | - |
| entworf fir | Pad & Tablet |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | MIPI (2 ch, 4 data lanes) Connector |
| Ëmwelt | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| B079XAN02.0 CELL | AUO | 7.9 | 768×1024 |
| B080XAN02.0 | AUO | 7.9 | 768×1024 |
| B080XAN03.0 | AUO | 7.9 | 768×1024 |
| LJ640U21 | SHARP | 7.9 | 640×200 |
| LP079QX1-SP0V | LG Display | 7.9 | 1536×2048 |
| LP079X01-SMA1 | LG Display | 7.9 | 768×1024 |
| LQ079L1SX01 | SHARP | 7.9 | 1536×2048 |
| LQ079L1SX02 | SHARP | 7.9 | 1536×2048 |
| PA079DS4 | E Ink | 7.9 | 480×234 |
| PA080XS2 | E Ink | 7.9 | 480×468 |
