AUO T320XVN01.0 CELL Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


T320XVN01.0 CELL

T320XVN01.0 CELL
T320XVN01.0 CELL
T320XVN01.0 CELL
T320XVN01.0 CELL thumb T320XVN01.0 CELL thumb T320XVN01.0 CELL thumb
Mark
AUO
Gréisst
31.5
Applikatioun
LCTV
Opléisung
1366×768
Zesummesetzung
CELL
Hellegkeet
0
CR
3000:1
Faarwen
16.7M
Backlight
No B/L
Interface
LVDS
In Stock
9
Spezifikatioune

Part Number T320XVN01.0 CELL
MarkAUO
Gréisst31.5
ApplikatiounLCTV
Opléisung1366×768
ZesummesetzungCELL
Hellegkeet0
CR3000:1
Faarwen16.7M
GéigeliichtNo B/L
InterfaceLVDS
Panel MarkAUO
Panel ModellT320XVN01.0 CELL
Panel Typ a-Si TFT-LCD , CELL
Panel Gréisst31.5 inch
Resolutioun1366×768(RGB) , WXGA
Display ModusAMVA, Normally Black, Transmissive
aktiv Beräich697.685×392.256 mm
skizzéieren716.1×408.7 mm
UewerflächAntiglare (Haze 2%), Hard coating (3H)
Glas Déift0.50+0.50 mm
transmissivitéit6.1% (Typ.)(with Polarizer)
Kontrast Verhältnis3000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193178%
Äntwert Zäit6.5 (Typ.)(G to G)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
LC320W01-SL01 LG Display 31.5 1366×768
MT3151A05-2 CSOT 31.5 1366×768
T320XVN01.0 AUO 31.5 1366×768
T320XVN01.0 CELL AUO 31.5 1366×768
T320XVN02.0 AUO 31.5 1366×768
T320XVN02.0 CELL AUO 31.5 1366×768
T320XVN02.9 CELL AUO 31.5 1366×768
T320XVN02.A CELL AUO 31.5 1366×768
T320XVN05.0 AUO 31.5 1366×768
V315B5-L01 Innolux 31.5 1366×768
