| Part Number | AX080E002B |
| Mark | KOE |
| Gréisst | 31.5 |
| Applikatioun | LCTV |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 500 |
| CR | 950:1 |
| Faarwen | 16.7M |
| Géigeliicht | EEFL |
| Interface | LVDS |
| Panel Mark | IPS Alpha |
| Panel Modell | AX080E002B |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 31.5 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | IPS-Pro, Normally Black, Transmissive |
| aktiv Beräich | 697.685×392.256 mm |
| skizzéieren | 760×450 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 950:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 8/6 (Typ.)(Tr/Td); 17 (Typ.)(MPRT) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 16 pcsEEFLEmbedded (Inverter) |
| Signal Interface | LVDS (1 ch, 8-bit), 41 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
