AUO T260XW02 VB Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


T260XW02 VB

T260XW02 VB
T260XW02 VB
T260XW02 VB thumb T260XW02 VB thumb
Mark
AUO
Gréisst
26.0
Applikatioun
LCTV
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
500
CR
800:1
Faarwen
16.7M
Backlight
CCFL
Interface
LVDS
In Stock
81
Spezifikatioune

Part Number T260XW02 VB
MarkAUO
Gréisst26.0
ApplikatiounLCTV
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet500
CR800:1
Faarwen16.7M
GéigeliichtCCFL
InterfaceLVDS
Panel MarkAUO
Panel ModellT260XW02 VB 0 Compatible model
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst26.0 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusVA, Normally Black, Transmissive
aktiv Beräich575.769×323.712 mm
skizzéieren626×373 mm
UewerflächAntiglare (Haze 13%), Hard coating (3H)
Hellegkeet500 cd/m² (Typ.)
Kontrast Verhältnis800:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit21/4 (Typ.)(Tr/Td); 8 (Typ.)(G to G)
Vue Wénkel85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ14 pcsCCFLEmbedded (Inverter)
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
T260XVN01.1 AUO 26.0 1366×768
T260XVN01.4 AUO 26.0 1366×768
T260XW01 V3 AUO 26.0 1280×768
T260XW02 V0 AUO 26.0 1366×768
T260XW02 V9 AUO 26.0 1366×768
T260XW03 V2 AUO 26.0 1366×768
T260XW04 V5 AUO 26.0 1366×768
T260XW04 V7 AUO 26.0 1366×768
T260XW04 V8 AUO 26.0 1366×768
T260XW06 V5 AUO 26.0 1366×768
