T260XW04 V5

T260XW04 V5
T260XW04 V5 thumb
Mark
AUO
Gréisst
26.0
Applikatioun
LCTV
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
450
CR
3000:1
Faarwen
16.7M
Backlight
CCFL
Interface
LVDS
In Stock
2
Spezifikatioune

Part Number T260XW04 V5
MarkAUO
Gréisst26.0
ApplikatiounLCTV
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet450
CR3000:1
Faarwen16.7M
GéigeliichtCCFL
InterfaceLVDS
Panel MarkAUO
Panel ModellT260XW04 V5
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst26.0 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusAMVA, Normally Black, Transmissive
aktiv Beräich575.769×323.712 mm
skizzéieren626×373 mm
UewerflächAntiglare (Haze 13%), Hard coating (3H)
Hellegkeet450 cd/m² (Typ.)
Kontrast Verhältnis3000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit6.5 (Typ.)(G to G)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ4 pcsCCFLEmbedded (Inverter)
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
T260XVN01.1 AUO 26.0 1366×768
T260XW02 V0 AUO 26.0 1366×768
T260XW02 V9 AUO 26.0 1366×768
T260XW02 VB AUO 26.0 1366×768
T260XW02 VP AUO 26.0 1366×768
T260XW02 VS AUO 26.0 1366×768
T260XW03 V2 AUO 26.0 1366×768
T260XW04 V2 AUO 26.0 1366×768
T260XW04 V6 AUO 26.0 1366×768
T260XW05 V0 AUO 26.0 1366×768
