| Part Number | SG2701B01-3 |
| Mark | CSOT |
| Gréisst | 27.0 |
| Applikatioun | Desktop Monitor Gami |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 4000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | LVDS |
| Mark | CSOT |
| Modell | SG2701B01-3 |
| diagonal Gréisst | 27.0 inch |
| Typ | a-Si TFT-LCD, CELL |
| Pixel Format | 1920(RGB)×1080 [FHD] 81PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 597.888(H)×336.312(V) mm |
| kontur dim. | 608.888(H)×348.337(V) ×1.3(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare (Haze 25%) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 4000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 12 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Betribssystemer Modus | HVA, Normally Black, Transmissive |
| Plackedicke | 0.40+0.50 mm |
| Iwwerdroung | 4.6% (Typ.)(with Polarizer) |
| Ënnerstëtzung Faarf | 16.7M 99% sRGB |
| Liichtquell | No B/L |
| Gewiicht | - |
| entworf fir | Desktop Monitor Gaming |
| Frame Taux | 165Hz |
| Touch Panel | Without |
| d-ic detail | COF Built-in 6 source chips |
| Interface Typ | LVDS (4 ch, 8-bit) , 61 pins Connector |
| Stroumversuergung | 12.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
