| Part Number | RGS10096064FR020 |
| Mark | RiTdisplay |
| Gréisst | 0.95 |
| Applikatioun | IA |
| Opléisung | 96×64 |
| Zesummesetzung | OLED |
| Hellegkeet | 100 |
| CR | 2000:1 |
| Faarwen | 65K |
| Géigeliicht | self |
| Interface | CPU/SPI |
| Panel Mark | RiTdisplay |
| Panel Modell | RGS10096064FR020 |
| Panel Typ | PM-OLED , OLED |
| Panel Gréisst | 0.95 inch |
| Resolutioun | 96(RGB)×64 |
| aktiv Beräich | 20.135×13.42 mm |
| skizzéieren | 24.2×20.9×1.51 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 100 cd/m² (Typ.) |
| Kontrast Verhältnis | 2000 : 1 (Typ.) |
| weisen Faarwen | 65K |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 85Hz |
| Chauffeur ic | COG Built-in SEPS114A |
| Signal Interface | 8-bit 6800/8080 parallel, 4-wire SPI, 34 pins |
| Input Volt | 13.0V (Typ.)(VCC) |
| Applikatioun | IA |
