| Part Number | RGC13128096FH004 |
| Mark | RiTdisplay |
| Gréisst | 1.3 |
| Applikatioun | Handheld & PDA |
| Opléisung | 128×96 |
| Zesummesetzung | PM-OLED, OLED |
| Hellegkeet | |
| CR | 2000:1 |
| Faarwen | 65K/262K |
| Géigeliicht | self |
| Interface | 8-bit |
| Mark | RiTdisplay |
| Modell | RGC13128096FH004 |
| diagonal Gréisst | 1.3 inch |
| Typ | PM-OLED, OLED |
| Pixel Format | 128(RGB)×96 123PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 26.279(H)×19.708(V) mm |
| kontur dim. | 33(H)×25.8(V) ×1.31(D) mm |
| bezel Beräich | 28.3(H)×21.7(V) mm |
| Behandlung | Antiglare |
| luminance | 90 cd/m² (Typ.) |
| Kontrast Verhältnis | 2000:1 (Min.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 0.01 (Typ.) |
| Vue Wénkel | 80/80/80/80 (Min.) |
| Betribssystemer Modus | - |
| Ënnerstëtzung Faarf | 65K/262K 66% NTSC |
| Liichtquell | self , 11K hours |
| Gewiicht | 2.30±0.23g |
| entworf fir | Handheld & PDA |
| Frame Taux | 105Hz |
| Touch Panel | Without |
| d-ic detail | COF Built-in SSD1351UR1 |
| Interface Typ | 8-bit 6800/8080 parallel , 30 pins FPC |
| Stroumversuergung | 15/2.8/1.8V (Typ.)(VCC/VCI/VDDIO) |
| Ëmwelt | Operating Temperature: -40 ~ 70 °C ; Storage Temperature: -40 ~ 85 °C |
