| Part Number | PT035TN01 V.6 |
| Mark | Innolux |
| Gréisst | 3.5 |
| Applikatioun | PND |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 300:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Parallel/Serial |
| Panel Mark | INNOLUX |
| Panel Modell | PT035TN01 V.6 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 3.5 inch |
| Resolutioun | 320(RGB)×240 , QVGA |
| Display Modus | TN, Normally White, TMR |
| aktiv Beräich | 70.08×52.56 mm |
| skizzéieren | 78.2×65×4.8 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 300 : 1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 15/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6S1PWLEDWithout Driver |
| Signal Interface | Digital RGB (8/24-bit) + SPI, CCIR601/656, 60 pins |
| Input Volt | 3.3/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| Applikatioun | PND |
