| Part Number | DLC0350BMG-1 |
| Mark | Other |
| Gréisst | 3.5 |
| Applikatioun | MPH |
| Opléisung | 240×320 |
| Zesummesetzung | LCM |
| Hellegkeet | 100 |
| CR | 150:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | DLC |
| Panel Modell | DLC0350BMG-1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 3.5 inch |
| Resolutioun | 240(RGB)×320 , QVGA |
| Display Modus | TN, Normally White, Transflective |
| aktiv Beräich | 53.64×71.52 mm |
| skizzéieren | 64×85×3.13 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 100 cd/m² (Typ.) |
| Kontrast Verhältnis | 150:1 (Typ.)(Transmissive)6.5:1 (Typ.)(Reflective) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| Input Volt | 2.8/15/-10V (Typ.)(VCC/VGH/VGL) |
| Applikatioun | MPH |
