| Part Number | P270DAN01.0 |
| Mark | AUO |
| Gréisst | 27.0 |
| Applikatioun | Digital Signage |
| Opléisung | 2560×1440 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 1.07B |
| Géigeliicht | GB-LED , 30K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 27.0 inch |
| Pixel Zuel | 2560(RGB)×1440 (Quad-HD) 108PPI |
| aktiv Beräich (mm) | 596.736 × 335.664 (H×V) |
| Bezel Beräich (mm) | 601.6 × 340.15 (H×V) |
| luminance | 350 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 1.07B 99% Adobe RGB |
| mass | - |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (4 ch, 10-bit) , 92 pins Connector |
| Spannungsversuergung | 5.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Modell Numm | P270DAN01.0 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 630 × 371.8 (H×V×D) |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Äntwert | 12 (Typ.)(G to G) ms |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| benotzt fir | Digital Signage |
| touchscreen | Without |
