LG Display LM270WF5-SSA1 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


LM270WF5-SSA1

LM270WF5-SSA1
LM270WF5-SSA1
LM270WF5-SSA1 thumb LM270WF5-SSA1 thumb
Mark
LG Display
Gréisst
27.0
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
250
CR
1000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
347
Spezifikatioune

Part Number LM270WF5-SSA1
MarkLG Display
Gréisst27.0
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet250
CR1000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkLG Display
Panel ModellLM270WF5-SSA1
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst27.0 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusS-IPS, Normally Black, Transmissive
aktiv Beräich597.888×336.312 mm
skizzéieren617.1×361.3×14.75 mm
UewerflächAntiglare (Haze 25%)
Hellegkeet250 cd/m² (Typ.)
Kontrast Verhältnis1000:1 (Typ.)
weisen Faarwen16.7M (6-bit + Hi-FRC), CIE193172%
Äntwert Zäit14 (Typ.)(G to G)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ14S4PWLEDWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
