| Part Number | P101KDA-AK0 |
| Mark | Innolux |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1200×1920 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , 15K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | Innolux |
| Écran Gréisst | 10.1 inch |
| Pixel Zuel | 1200(RGB)×1920 (WUXGA) 225PPI |
| aktiv Beräich (mm) | 135.36 × 216.576 (H×V) |
| Bezel Beräich (mm) | - |
| luminance | 400 (Typ.)(cd/m²) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 70% NTSC |
| mass | 105g (Max.) |
| Erfrëschungsrate | 60Hz |
| Modell Numm | P101KDA-AK0 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 142.96 × 235.887 × 3.3 (H×V×D) |
| Behandlung | Glare (Haze 0%), Hard coating |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Aarbecht Modus | AAS, Normally Black, Transmissive |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| benotzt fir | Pad & Tablet |
| touchscreen | Without |
