| Part Number | NV101WXM-N51 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Panel Mark | BOE |
| Panel Gréisst | 10.1" |
| Resolutioun | 1280(RGB)×800, WXGA, 149PPI |
| Affichage Beräich | 216.96(W)×135.6(H) mm |
| Kontur Gréisst | 228.21(W)×148.86(H) ×4.59(D) mm |
| Hellegkeet | 250 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 50% NTSC |
| Frequenz | 60Hz |
| Gewiicht | 145g (Max.) |
| Panel Modell | NV101WXM-N51 (BOE070B) |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Glare (Haze 0%), Hard coating (2H), Antireflection |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | ADS, Normally Black, Transmissive |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Lampe Typ | WLED , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Pad & Tablet |
