| Part Number | NL6448BC18-03F |
| Mark | NLT |
| Gréisst | 5.7 |
| Applikatioun | IA |
| Opléisung | 640×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 800 |
| CR | 850:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | NEC |
| Panel Modell | NL6448BC18-03F 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.7 inch |
| Resolutioun | 640(RGB)×480 , VGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 116.16×87.12 mm |
| skizzéieren | 135×104.6×10.9 mm |
| Uewerfläch | Clear, Hard coating (3H) |
| Hellegkeet | 800 cd/m² (Typ.) |
| Kontrast Verhältnis | 850:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193160% |
| Äntwert Zäit | 3/15 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 9S2P×2CNWLEDWithout Driver |
| Signal Interface | CMOS (1 ch, 6-bit), 33 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | IA |
