| Part Number | NL6448AC33-A1D |
| Mark | NLT |
| Gréisst | 10.4 |
| Applikatioun | Industrial |
| Opléisung | 640×480 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 262K |
| Géigeliicht | WLED , 100K hours , With LED Driver |
| Interface | |
| Fabrikant beschwéiert | NLT |
| Modell Numm | NL6448AC33-A1D |
| Écran Gréisst | 10.4 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 640(RGB)×480 (VGA) 76PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 211.2 × 158.4 (H×V) |
| Kontur (mm) | 227.3 × 177.5 × 9.8 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare |
| luminance | 370 cd/m² (Typ.) |
| Kontrast Verhältnis | 900 : 1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Äntwert | 18 (Typ.)(Tr+Td) ms |
| gutt Vue op | - |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 262K |
| mass | 380g (Max.) |
| benotzt fir | Industrial |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| NL6448AC33-05 | NLT | 10.4 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-24 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
