| Part Number | NL3224AC35-09 |
| Mark | NEC |
| Gréisst | 5.5 |
| Applikatioun | Industrial |
| Opléisung | 320×240 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | - |
| Interface | |
| Panel Mark | NEC |
| Panel Gréisst | 5.5" |
| Resolutioun | 320(RGB)×240, QVGA, 72PPI |
| Affichage Beräich | 111.36(W)×83.52(H) mm |
| Hellegkeet | - |
| Vue Wénkel | - |
| beschte Vue op | - |
| weisen Faarwen | 262K |
| Frequenz | 60Hz |
| Gewiicht | - |
| Panel Modell | NL3224AC35-09 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Kontrast Verhältnis | 400:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 5/25 (Typ.)(Tr/Td) |
| Lampe Typ | |
| Touchscreens | Without |
| Applikatioun | Industrial |
