| Part Number | BT055FWM-N00 |
| Mark | BOE |
| Gréisst | 5.5 |
| Applikatioun | MPH |
| Opléisung | 480×854 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | BOE |
| Panel Modell | BT055FWM-N00 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.5 inch |
| Resolutioun | 480(RGB)×854 , FWVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 68.04×121.05 mm |
| skizzéieren | 72.34×130.86×2.3 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 5S2PWLEDWithout Driver |
| Signal Interface | MIPI (2 data lanes), 25 pins |
| Input Volt | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| Applikatioun | MPH |
