| Part Number | NL192108AC21-04 |
| Mark | NLT |
| Gréisst | 18.5 |
| Applikatioun | Industrial |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | NLT |
| Écran Gréisst | 18.5 inch |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 119PPI |
| aktiv Beräich (mm) | 408.96 × 230.04 (H×V) |
| Bezel Beräich (mm) | 413.4 × 234.0 (H×V) |
| luminance | 400 cd/m² (Typ.) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 72% NTSC |
| mass | 1.55/1.70Kgs (Typ./Max.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Spannungsversuergung | 5.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Modell Numm | NL192108AC21-04 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 430.4 × 254.6 × 14 (H×V×D) |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Äntwert | 12/13 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | UA-SFT, Normally Black, Transmissive |
| benotzt fir | Industrial |
| touchscreen | Without |
