| Part Number | M185BGE-L2U |
| Mark | Innolux |
| Gréisst | 18.5 |
| Applikatioun | DMPC |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 200 |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | CHIMEI INNOLUX |
| Panel Modell | M185BGE-L2U |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 18.5 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 409.8×230.4 mm |
| skizzéieren | 430.32×254.6×11 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 2/6 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 9S4PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| M185B1-L02 | Innolux | 18.5 | 1366×768 |
| M185B1-L07 | Innolux | 18.5 | 1366×768 |
| M185B3-LA1 | Innolux | 18.5 | 1366×768 |
| M185BGE-L10 | Innolux | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185BGE-L23 | Innolux | 18.5 | 1366×768 |
| M185BGE-L2U | Innolux | 18.5 | 1366×768 |
| M185BGE-P02 | Innolux | 18.5 | 1366×768 |
| LM190E09-TLK1 | LG Display | 19.0 | 1280×1024 |
| LM215DB-T02 | PANDA | 21.5 | 1920×1080 |
| LM215DT8A | PANDA | 21.5 | 1920×1080 |
| LM230WF5-TLD2 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLF1 | LG Display | 23.0 | 1920×1080 |
| LQ181E1DW28 | SHARP | 18.1 | 1280×1024 |
| M190ETN01.0 | AUO | 19.0 | 1280×1024 |
| M236HGE-L20 | Innolux | 23.6 | 1920×1080 |
| TMS150XG1-10TB | Tianma | 15.0 | 1024×768 |
| TX38D12VC0CAA | KOE | 15.0 | 1024×768 |
