| Part Number | NL12876BC15-01 |
| Mark | NLT |
| Gréisst | 8.9 |
| Applikatioun | NBPC |
| Opléisung | 1280×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 280 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | NEC |
| Panel Modell | NL12876BC15-01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 8.9 inch |
| Resolutioun | 1280(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 193.92×116.352 mm |
| skizzéieren | 209.2×130.3×7.7 mm |
| Uewerfläch | Clear, Hard coating (3H) |
| Hellegkeet | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193156% |
| Äntwert Zäit | 6/2 (Typ.)(Tr/Td) |
| Vue Wénkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 11S3PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
