| Part Number | NDS0708001280-31 |
| Mark | SEBO |
| Gréisst | 7.0 |
| Applikatioun | PAD |
| Opléisung | 800×1280 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SEBO |
| Panel Modell | NDS0708001280-31 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 800(RGB)×1280 , WXGA |
| Display Modus | Normally Black, Transmissive |
| aktiv Beräich | 94.2×150.72 mm |
| skizzéieren | 104.32×161.67×4.19 mm |
| Uewerfläch | |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 5S5PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 31 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| CLAA070LC0DCW | CPT | 7.0 | 800×480 |
| CLAA070NC0DCW | CPT | 7.0 | 1024×600 |
| G070Y2-T02 | Innolux | 7.0 | 800×480 |
| HSD070I651-C02 | HannStar | 7.0 | 480×234 |
| HT07W12-200 | HYDIS | 7.0 | 480×234 |
| LMS700JF04-0 | Samsung | 7.0 | 1024×600 |
| N070LGE-L21 | Innolux | 7.0 | 1024×600 |
| NDS0708001280-31 | SEBO | 7.0 | 800×1280 |
| VVF07H119A90 | Panasonic | 7.0 | 800×1280 |
| A090PAN01.0 | AUO | 9.0 | 900×1440 |
| B080XAN01.0 | AUO | 7.9 | 768×1024 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| LD070WX5-SM01 | LG Display | 7.0 | 900×1440 |
| LP079X01-SMA2 | LG Display | 7.9 | 768×1024 |
| LTN101AL01-F01 | Samsung | 10.1 | 1280×800 |
| M101NWWB R6 | IVO | 10.1 | 1280×800 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| VVF07H119A90 | Panasonic | 7.0 | 800×1280 |
