| Part Number | N184H4-L01 |
| Mark | Innolux |
| Gréisst | 18.4 |
| Applikatioun | NBPC |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | CMO |
| Panel Modell | N184H4-L01 2 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 18.4 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 408.96×230.04 mm |
| skizzéieren | 422.5×248×6.5 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 2/6 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 2 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| LTM184HL01 | Samsung | 18.4 | 1920×1080 |
| LTN184KT01-101 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-F01 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-S02 | Samsung | 18.4 | 1680×945 |
| LTN184KT02-T01 | Samsung | 18.4 | 1680×945 |
| N184H3-L02 | Innolux | 18.4 | 1920×1080 |
| N184H4-L01 | Innolux | 18.4 | 1920×1080 |
| N184H4-L04 | Innolux | 18.4 | 1920×1080 |
| N184H6-L02 | Innolux | 18.4 | 1920×1080 |
| HT140WXB-100 | BOE | 14.0 | 1366×768 |
| LP101WH1-TLA1 | LG Display | 10.1 | 1366×768 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LQ164M1LD4CV | SHARP | 16.4 | 1920×1080 |
| LT121S1-101 | Samsung | 12.1 | 800×600 |
| LTN141X7-L06 | Samsung | 14.1 | 1024×768 |
| LTN154AT01-A01 | Samsung | 15.4 | 1280×800 |
| LTN156AT02-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT24-B01 | Samsung | 15.6 | 1366×768 |
| N133BGE-L31 | Innolux | 13.3 | 1366×768 |
