| Part Number | HT140WXB-100 |
| Mark | BOE |
| Gréisst | 14.0 |
| Applikatioun | NBPC |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 220 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | HT140WXB-100 30 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 14.0 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 309.399×173.952 mm |
| skizzéieren | 323.5×192×5.2 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | Glare (Haze 0%), Hard coating (3H) |
| Hellegkeet | 220 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193160% |
| Äntwert Zäit | 8 (Typ.)(Tr+Td) |
| Vue Wénkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S6PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| BT140GW01 V.0 | Innolux | 14.0 | 1366×768 |
| HT140WXB-100 | BOE | 14.0 | 1366×768 |
| HT140WXB-501 | BOE | 14.0 | 1366×768 |
| HT140WXB-601 | BOE | 14.0 | 1366×768 |
| LP140WH1-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TLB3 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TLD2 | LG Display | 14.0 | 1366×768 |
| LTN140AT16-401 | Samsung | 14.0 | 1366×768 |
| N140BGE-L33 | Innolux | 14.0 | 1366×768 |
| N140FGE-L32 | Innolux | 14.0 | 1600×900 |
| B141XN03 V0 | AUO | 14.1 | 1024×768 |
| B156XTN04.5 | AUO | 15.6 | 1366×768 |
| LP121X1-A2M1 | LG Display | 12.1 | 1024×768 |
| LP154W02-TL06 | LG Display | 15.4 | 1680×1050 |
| LP156WF1-TLF3 | LG Display | 15.6 | 1920×1080 |
| LQ133K1LD4B | SHARP | 13.3 | 1280×800 |
| LQ13X32 | SHARP | 13.3 | 1024×768 |
| LTN141AT12-J01 | Samsung | 14.1 | 1280×800 |
| LTN170CT03-004 | Samsung | 17.0 | 1920×1200 |
| N140BGE-E33 | Innolux | 14.0 | 1366×768 |
