MT190AW02 V.Y

MT190AW02 V.Y
MT190AW02 V.Y
MT190AW02 V.Y
MT190AW02 V.Y thumb MT190AW02 V.Y thumb MT190AW02 V.Y thumb
Mark
Innolux
Gréisst
19.0
Applikatioun
DMPC
Opléisung
1440×900
Zesummesetzung
LCM
Hellegkeet
300
CR
1000:1
Faarwen
16.7M
Backlight
CCFL
Interface
LVDS
In Stock
40
Spezifikatioune

Part Number MT190AW02 V.Y
MarkInnolux
Gréisst19.0
ApplikatiounDMPC
Opléisung1440×900
ZesummesetzungLCM
Hellegkeet300
CR1000:1
Faarwen16.7M
GéigeliichtCCFL
InterfaceLVDS
Panel MarkINNOLUX
Panel ModellMT190AW02 V.Y
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst19.0 inch
Resolutioun1440(RGB)×900 , WXGA+
Display ModusTN, Normally White, Transmissive
aktiv Beräich408.24×255.15 mm
skizzéieren428×278×16.5 mm
UewerflächAntiglare (Haze 25%), Hard coating (3H)
Hellegkeet300 cd/m² (Typ.)
Kontrast Verhältnis1000:1 (Typ.)
weisen Faarwen16.7M (6-bit + Hi-FRC), CIE193172%
Äntwert Zäit1.5/3.5 (Typ.)(Tr/Td)
Vue Wénkel85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ4 pcsCCFLWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
Famill Modell
LM190E08-TLL1 LG Display 19.0 1280×1024
MT190AW01 V.5 Innolux 19.0 1440×900
MT190AW01 V.7 Innolux 19.0 1440×900
MT190AW01 V.C Innolux 19.0 1440×900
MT190AW02 V.0 Innolux 19.0 1440×900
MT190AW02 V.4 Innolux 19.0 1440×900
MT190AW02 V.A Innolux 19.0 1440×900
MT190AW02 V.V Innolux 19.0 1440×900
MT190AW02 V.W Innolux 19.0 1440×900
MT190AW02 V.Y Innolux 19.0 1440×900
